（1） Performance characteristics:

1. Fully intelligent design, capable of automatically handling abnormal situations, with multiple control programs that are simple, reliable, and easy to operate;

2. Precision casting dry heating with high control accuracy;

3. Fully enclosed structure, environmentally friendly exhaust purification system, efficient treatment of toxic and harmful gases;

4. After a power outage, continue working for 6-8 hours to automatically protect the dehydration organization from the impact of the power outage;

5. Using imported components, running smoothly and without noise, designed in accordance with ergonomic principles;

6. The surface of the body is sprayed with APS engineering plastic, which has high strength, corrosion resistance, smooth lines, and an elegant appearance;

7. Timed startup.

（2） Main technical parameters:

1. Number of hydraulic cylinders: 12 (9 reagent cylinders, 3 wax melting cylinders)

2. Single cylinder capacity: 1000ml/2000ml

3. Sample capacity: 50 standard embedding boxes

4. Programmable: 20 sets

5. Single cylinder processing time: Any setting within 0-100 hours for cylinder 1, and any setting within 0-24 hours for cylinder 2 to 12

6. The retention and drainage time for changing cylinders is adjustable from 10 to 60 seconds;

7. Organizational protection cylinder: cylinders 1-7 can be set arbitrarily;

8. Temperature preset range: room temperature~99 ℃ adjustable

9. Mixing frequency: 0-6 times/minute adjustable;

10 Heating control: Dry internal heating, automatic judgment of heating time, energy-saving and energy-saving, temperature control accuracy ± 1-2 ℃

11 Power supply: AC220V ± 10% 50Hz ± 1Hz Power: ≤ 800VA

12 External dimensions: 1010X430x450/1050x470x490
